Ahjm4Dp Jackplate Microjacker 4" 115Hp | T-H Marine
T-H Marine Atlas Micro Jacker For Outboards Up to 115HP (Max Wt 425 lbs.)
SKU:
232-AHJM4DPCategory:
Jack PlatesBrand:
The smallest and lightest hydraulic jack on the market is ideal for shallow water skiffs and flats boats. It has a footprint of only 14-5/8" W x 11-1/2" H with a weight of only 23 lbs. The strong, self-contained actuator takes only 8 seconds to go from top to bottom and has 5" of travel. 3 mounting hole options on the transom side and 2 on the engine side. Optional adapter available to accommodate clamp-on outboard motors if needed.
Specifications |
|
_Application |
115hp |
_Setback |
4" |
Shipping Details |
|
Weight |
23.00 lb |
Length |
15.00 in |
Height |
4.00 in |
Width |
14.50 in |
